5982, 5984 and 5985 Dimensions
Product Support: www.instron.com
Table 2-5. 5982 with Single Test Space
Dimension - mm (in) Letter
Frame
Option
Standard
Height and
Width Extra Height Extra Wide
Extra Height
and Extra
Wide
Top plate length A 1105 (43.5) 1105 (43.5) 1464 (57.6) 1464 (57.6)
Horizontal test space B 575 (22.6) 575 (22.6) 934 (36.8) 934 (36.8)
Crosshead thickness D 148 (5.8) 148 (5.8) 200 (7.9) 200 (7.9)
Minimum crosshead
position
E1 100 (3.9) 100 (3.9) 100 (3.9) 100 (3.9)
Maximum crosshead
position
E2 1430 (56.3) 1930 (76) 1430 (56.3) 1930 (76)
Overall height F 2273 (89.5) 2773 (109.2) 2273 (89.5) 2773 (109.2)
Overall height with
optional base extension
2573 (101.3) 3073 (121) 2573 (101.3) 3073 (121)
Overall width G 1130 (44.5) 1130 (44.5) 1489 (58.6) 1489 (58.6)
Load cell height J 110 (4.3) 110 (4.3) 110 (4.3) 110 (4.3)
Table 2-6. 5984 and 5985 with Single Test Space
Dimension - mm (in) Letter
Frame
Option
Standard
Height and
Width Extra Height Extra Wide
Extra Height
and Extra
Wide
Top plate length A 1105 (43.5) 1105 (43.5) 1464 (57.6) 1464 (57.6)
Horizontal test space B 575 (22.6) 575 (22.6) 934 (36.8) 934 (36.8)
Crosshead thickness D 200 (7.9) 200 (7.9) 225 (8.9) 225 (8.9)
Minimum crosshead
position
E1 100 (3.9) 100 (3.9) 75 (2.9) 75 (2.9)
Maximum crosshead
position
E2 1430 (56.3) 1930 (76) 1405 (55.3) 1905 (75)
Overall height F 2273 (89.5) 2773 (109.2) 2273 (89.5) 2773 (109.2)
