Instron 5984 - Page 46

Chapter: Requirements and Specifications
2-26 M10-16250-EN
Figure 2-13. 5988 and 5989 Crosshead Mounting Dimensions
90
45
280
266.7
700
140
60°
350
M10 x 25 Deep
(10X)
Ø100
Ø60 x 3 Deep
M20 x 50 Deep
(2X)
A
B
5988 “A” =Ø51 Thru and “B” = Ø60 x 3 Deep
5989 “A” = 74.75 thru and “B” = Ø82.6 x 5 Deep
Underside of Crosshead
280
700
90 45
140
350
M10 x 25 Deep
(4X)
M20 x 50 Deep
(2X)
Topside of Crosshead
