Instron 5985 - Page 44

Chapter: Requirements and Specifications
2-24 M10-16250-EN
Figure 2-11. 5982 Second Test Space Configuration - Fixed Crosshead Mounting
Dimensions
482
241
Topside of Crosshead
Ø32 Thru
Ø100
Front of frame
Ø11 Thru
(6X)
M16 x 35 Deep
(8X)
280
90
140
45
Underside of Crosshead
M10 x 25 Deep
(10X)
Ø100
Ø60 x 3 Deep
