2-25
Accessory Mounting Dimensions
Product Support: www.instron.com
Figure 2-12. 5984 and 5985 Second Test Space Configuration - Fixed Crosshead Mounting
Dimensions
482
65
130
241
75
38
Front of frame
Ø22 Thru
Ø31.75 x 28
(4X)
M16 x 35
(2X)
Ø51 Thru
Deep
280
140
90
45
75
38
Underside of Crosshead
Topside of Crosshead
Ø60 x 3 Deep
M10 x 25 Deep
(10X)
