Chapter: Specifications
44 M10-17417-EN
Displacement (crosshead position) display accuracy Under no load conditions, equal or less than ±
0.01 mm (0.0004 in) or ±
0.05% of displayed
reading, whichever is greater.
Displacement (crosshead position) repeatability - mm
(in)
± 0.015 (0.0006)
Load measurement accuracy ± 0.5% of reading down to 1/1000 of load cell
capacity.
Strain measurement accuracy ± 0.5% of reading down to 1/50 of full scale
with ASTM E83 class B or ISO 9513 class 0.5
extensometer
Crosshead position control resolution - µm 0.00494
Table 12. 68TM-10 system performance (Continued)
Parameter Specifications
