Integra DHC-80.2 Service Manual

1/157 PAGE
DHC-80.2
<Note>
Parts marked by "NSP" are generally unavailable because <Notes>
they are not in our Master Spare Parts List.
<MDD> : 120V,USA model
<MMA> : 220/230-240V,Australian model
DHC-80.2
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[CHASSIS SCREW]
A147 CUSHION (BUTYL) 1 28141748 <B>
A149 IB CUSHION W15*3t TAPE 1 28141585 <B>
A151 CHASSIS --- 1 27100493E <B>
A153 LEG --- 4 27175455
N
<B>
A155 CUSHION (LEG) 4 28141735 <B>
A157 IB CUSHION W15*3t TAPE 1 28141585 <B>
A158 CUSHION (BUTYL) 1 28141748 <B>
A159 CUSHION --- 8 28141637 <B>
A161 SCREW 3TTB+8B(3CM)SR 4 801637 <B>
A163 HOLDER (SPD-6) 6 27191308 <B>
A165 HOLDER KGPS-10RF 3 27190813 <B>
A167 HOLDER KGLS-10RT 1 27190428A <B>
A169 HOLDER KGLS-12RT 1 27190266 <B>
A173 HOLDER HOLDER KGLS-18S 1 27190470 <B>
A175 HOLDER KGPS-18S 1 27191339 <B>
A177 HOLDER KGLS-14S 1 27190164 <B>
A179 HOLDER SPM-4 1 27191154 <B>
A181 HOLDER KGLS-22RT 3 27190772 <B>
A183 HOLDER HOLDER KGLS-18S 1 27190470 <B>
A185 HOLDER KGLS-22RT 1 27190772 <B>
A186 CUSHION (FNP) t25x15x10 2 28141828 <B>
A189 SCREW 3TTB+8B(3CM)SR 1 801637 <B>
A191 SCREW 3TTB+8B(3CM)SR 1 801637 <B>
A193 SCREW 3TTB+8B(3CM)SR 1 801637 <B>
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
