SCHEMATIC DIAGRAMS-14 / PART-16
E-CONTROL SECTION
DTR-30.1/DTR-20.1
A
1
2
3
4
BCDE
TX
+4VDSP
GNDDSP
GNDDSP
ECON_RST
ECON_RXD
ECON_TXD
RX
BALAN-0066
TO BAHDM-0060
PART-13:B5
TO BAHDM-0063
PART-13:B5
TO BAETC-0067
PART-17:E5
+3.3V
+3.3V
+3.3V
C4505
104Z
Q4501
PIC18F66J60
1
RE1/P2C
2
RE0/P2D
3
RB0/INT0/FLT0
4
RB1/INT1
5
RB2/INT2
6
RB3/INT3
7
MCLR
8
RG4/CCP5/P1D
9
VSS
10
VDDcore/vCAP
11
RF7/SS2
12
RF6/AN11
13
RF5/AN10/CVref
14
RF4/AN9
15
RF3/AN8
16
RF2/AN7/C1OUT
17
17:RF1/AN6/C2OUT
18
18:ENVREG
19
AVdd
20
AVss
21
RA3/AN3/Vref+
22
RA2/AN2/VRef-
23
RA1/LEDB/AN1
24
RA0/LEDA/AN0
25
Vss
26
Vdd
27
RA5/AN4
28
RA4/T0CK1
29
RC1
30
RC0
31
TX1
32
RX1
33
RC2
34
SCK1/SCL1
35
SDI1/SDA1
36
SDO1
37
PGD
38
VDD
39
CLKI
40
CLKO
41
VSS
42
PGC
43
RB5
44
RB4
45
Vssrx
46
TPIN-
47
TPIN+
48
Vddrx
49
Vddtx
50
TPOUT-
51
TPOUT+
52
Vsstx
53
RBAIAS
54
VddPLL
55
VSSPLL
56
VSS
57
VDD
58
RD2
59
RD1
60
RD0
61
RE5
62
RE4
63
RE3
64
RE2
C4508
10/50
R4524
330
R4525
330
L4503
BLM21PG221SN1
R4502
49.9_1%
R4501
49.9_1%
R4503
49.9_1%
R4504
49.9_1%
L4504
DLP2ADN900HL4L
1
2
3
4 5
6
7
8
C4502
103K
C4503
103K
R4506
330
R4507
330
C4509
15p
C4507 15p
R4529
47
R4528
47
R4527
47
R4526
47
+3.3V
+3.3V
C4510
104Z
R4510
10K
R4509
470
Q4503
BA33BC0FP
3
O
2
G
1
I
C4501
104Z
C4506
104Z
D4501
D4502
L4501
BLM21PG221SN1
C4515
104Z
C4512
104Z
C4516
100/16
C4511
100/16
R4505
2.2K
Q4502
IS25C02-2GLI
1
CS
2
SO
3
WP
4
GND
5
SI
6
SCK
7
HOLD
8
VCC
JL201B
1
2
3
JL4001B
3
2
1
X4501
XTAL
HC-49USSMD25.00MHz
R4508
10K
L4502
BLM21PG221SN1
R4530
10K
R4511
10
R4512
10
R4531
10K
R4532
10K
P4511
P4512
P4510
JTAG
2
4
6 5
3
1
P4501 J0026D21B/NL
ETHERNET
(E-CONTROL)
7
6
8
1
3
2
4
5
9
10
12
11
13
14
U007
E-CONTROL PC BOARD
2 Kbit EEPROM
ETHERNET
MICROCONTROLLER
WITH 1Mbit FLASH
