1/93 PAGE
DTR-30.1
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
<DD> : 120V,USA model
<PA> : 230V,Australian model
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REARKS
[SEMI CONDUCTOR]
Q6050 TR 2SC4468-O 1 2202523 <DD>
Q6050 TR
2SC5242-O
1
2202843
<PA>
Q6050 or TR 2SC4468-Y ( 1) 2202524 <DD>
Q6050 or TR 2SC4468-P ( 1) 2202526 <DD>
Q6050 or
TR
2SC5242-R
( 1)
2202842
<PA>
Q6050 or TR MN130S-O ( 1) 2203663 <DD>
Q6050 or TR MN130S-Y ( 1) 2203664 <DD>
Q6050 or TR MN130S-P ( 1) 2203666 <DD>
Q6050A ISO SHEET AC238 2 223024
Q6050B ISO SHEET ISO SHEET 6 223050
Q6051 TR 2SC4468-O 1 2202523 <DD>
Q6051 TR
2SC5242-O
1
2202843
<PA>
Q6051 or TR 2SC4468-Y ( 1) 2202524 <DD>
Q6051 or TR 2SC4468-P ( 1) 2202526 <DD>
Q6051 or
TR
2SC5242-R
( 1)
2202842
<PA>
Q6051 or TR MN130S-O ( 1) 2203663 <DD>
Q6051 or TR MN130S-Y ( 1) 2203664 <DD>
Q6051 or TR MN130S-P ( 1) 2203666 <DD>
Q6052 TR 2SC4468-O 1 2202523 <DD>
Q6052 TR
2SC5242-O
1
2202843
<PA>
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
