DTR-30.1
PC BOARD PARTS LIS
U001 Input selector/Volume/Power amp. pc board AS (BAAF-0014-1H)
U0011 Trans 2nd terminal pc board AS (BAPS-0015-1H)
U0012 Trans 2nd terminal pc board AS (BAPS-0016-1H)
U0013 Thermal sensor pc board AS (BAETC-0017-1H)
U0014 Holder pc board AS (BAETC-0018-1H)
U0015 Holder pc board AS (BAETC-0019-1H)
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REARKS
[SEMI CONDUCTOR]
D5671 ZENER D MTZJ7.5B 1 224470752T
D5672 ZENER D MTZJ7.5B 1 224470752T
D5700 C-DIODE KDS4148U 1 223283R2
D5700 or C-DIODE 1SS352 ( 1) 223234R2
D5700 or C-DIODE MA2J111 ( 1) 223279R2
D5701 C-DIODE KDS4148U 1 223283R2
D5701 or C-DIODE 1SS352 ( 1) 223234R2
D5701 or C-DIODE MA2J111 ( 1) 223279R2
D5707 C-DIODE KDS4148U 1 223283R2
D5707 or C-DIODE 1SS352 ( 1) 223234R2
D5707 or C-DIODE MA2J111 ( 1) 223279R2
D5708 C-DIODE KDS4148U 1 223283R2
D5708 or C-DIODE 1SS352 ( 1) 223234R2
D5708 or C-DIODE MA2J111 ( 1) 223279R2
D5717 C-DIODE KDS4148U 1 223283R2
D5717 or C-DIODE 1SS352 ( 1) 223234R2
D5717 or C-DIODE MA2J111 ( 1) 223279R2
D5718 C-DIODE KDS4148U 1 223283R2
D5718 or C-DIODE 1SS352 ( 1) 223234R2
D5718 or C-DIODE MA2J111 ( 1) 223279R2
D5800 DIODE RL1N4003 1 22380260T
D5801 DIODE RL1N4003 1 22380260T
D5802 DIODE RL1N4003 1 22380260T
D5803 DIODE RL1N4003 1 22380260T
D5804 DIODE RL1N4003 1 22380260T
