7/93 PAGE
A325 LABEL HOOKUP-INTEGRA 1 29363195 <DD>
A340 COVER (B) (Bent) 1 28210034
A340 COVER (B) (Not Bent) 1 28210034Z
A342 SCREW 3TTB+8B(3BC) 7 838430088GR
[TUNER UNIT]
U001 Input selector/Volume/Power amp. pc board AS BAAF-0014-1G 1 1B232514-1G N <DD>
U0011 Trans 2nd terminal pc board AS BAPS-0015-1G { 1} 1B232515-1G N <DD>
U0012 Trans 2nd terminal pc board AS BAPS-0016-1G { 1} 1B232516-1G N <DD>
U0013 Thermal sensor pc board AS BAETC-0017-1G { 1} 1B232517-1G N <DD>
U0014 Holder pc board AS BAETC-0018-1G { 1} 1B232518-1G N <DD>
U0015 Holder pc board AS BAETC-0019-1G { 1} 1B232519-1G N <DD>
U001 Input selector/Volume/Power amp. pc board AS BAAF-0014-1H 1 1B232514-1H N <PA>
U0011
Trans 2nd terminal pc board AS
BAPS-0015-1H
{ 1}
1B232515-1H
N
<PA>
U0012
Trans 2nd terminal pc board AS
BAPS-0016-1H
{ 1}
1B232516-1H
N
<PA>
U0013
Thermal sensor pc board AS
BAETC-0017-1H
{ 1}
1B232517-1H
N
<PA>
U0014
Holder pc board AS
BAETC-0018-1H
{ 1}
1B232518-1H
N
<PA>
U0015
Holder pc board AS
BAETC-0019-1H
{ 1}
1B232519-1H
N
<PA>
U002 MPU/CODEC pc board AS BADG-0025-1P 1 1B232525-1P N <DD>
U0021 Universal port pc board AS BAETC-0027-1P { 1} 1B232527-1P N <DD>
U002 MPU/CODEC pc board AS BADG-0025-1Q 1 1B232525-1Q N <PA>
U0021
Universal port pc board AS
BAETC-0027-1Q
{ 1}
1B232527-1Q
N
<PA>
U003 Diplay pc board AS BADIS-0046-1B 1 1B232546-1B N <DD>
U0031 Switch pc board AS BADIS-0047-1B { 1} 1B232547-1B N <DD>
U0032 Video pc board AS BAVD-0048-1B { 1} 1B232548-1B N <DD>
U0033 Power supply pc board AS BAPS-0049-1B { 1} 1B232549-1B N <DD>
U0034 Headphone pc board AS BAETC-0050-1B { 1} 1B232550-1B N <DD>
U0035 Inlet pc board AS BAETC-0051-1B { 1} 1B232551-1B N <DD>
U003 Diplay pc board AS BADIS-0046-1C 1 1B232546-1C N <PA>
U0031
Switch pc board AS
BADIS-0047-1C
{ 1}
1B232547-1C
N
<PA>
U0032
Video pc board AS
BAVD-0048-1C
{ 1}
1B232548-1C
N
<PA>
U0033
Power supply pc board AS
BAPS-0049-1C
{ 1}
1B232549-1C
N
<PA>
U0034
Headphone pc board AS
BAETC-0050-1C
{ 1}
1B232550-1C
N
<PA>
U0035
Inlet pc board AS
BAETC-0051-1C
{ 1}
1B232551-1C
N
<PA>
U004 HDMI,DSP pc board AS BAHDM-0063-1B 1 1B232563-1B N
U0041 Front HDMI pc board AS BAHDM-0064-1B { 1} 1B232564-1B N
U0042 Holder pc board AS BAETC-0065-1B { 1} 1B232565-1B N
U005 SP terminal pc board AS BATRM-0029-1H 1 1B232529-1H N <PA>
