42/93 PAGE
P8003A PLUG IMSA-9111B-16 1 25056620
P801 WS CLAMP CB-71683(L=50) 1 260261
U003 Diplay pc board AS (BADIS-0046-1B/C)
U0031 Switch pc board AS (BADIS-0047-1B/C)
U0032 Video pc board AS (BAVD-0048-1B/C)
U0033 Power supply pc board AS (BAPS-0049-1B/C)
U0034 Headphone pc board AS (BAETC-0050-1B/C)
U0035 Inlet pc board AS (BAETC-0051-1B/C)
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REARKS
[TUNER UNIT]
U7041 REMO SENS NJL34H380A 1 241365
[SEMI CONDUCTOR]
D2084 ZENER D UDZS6.8B 1 224550680R2
D7002 ZENER D UDZS8.2B 1 224550820R2
D7033 ZENER D UDZS3.9B 1 224550390R2
D7152 LED SLI-343URC-TE7 1 225449T
D7155 LED SLR-342MGTE7P 1 225455T
D7301 C-DIODE KDS4148U 1 223283R2 <1B,1C>
D7302 C-DIODE KDS4148U 1 223283R2 <1B,1C>
D7401 ZENER D UDZS5.1B 1 224550510R2
D7411 ZENER D UDZS6.8B 1 224550680R2
D7412 ZENER D UDZS6.8B 1 224550680R2
D9001 DIODE RL1N4003 1 22380260T
D9005 ZENER D UDZS36B 1 224553600R2
D9011 DIODE D5SBA20 1 22380130 <1B,1C>
D9011A SCREW 3P+10FN(3BC) 1 82143010GR <1B,1C>
D9011B HEAT SINK RAD-083 1 27160271 <1B,1C>
D9014 C-DIODE KDS4148U 1 223283R2
D9014 or C-DIODE 1SS352 ( 1) 223234R2
D9014 or C-DIODE MA2J111 ( 1) 223279R2
D9015 C-DIODE KDS4148U 1 223283R2
D9015 or C-DIODE 1SS352 ( 1) 223234R2
D9015 or C-DIODE MA2J111 ( 1) 223279R2
D9016 ZENER D UDZS7.5B 1 224550750R2
D9023 C-DIODE KDS4148U 1 223283R2
