Advanced Operations
En-54
Level Calibration
Here you can adjust the level of each speaker with the
built-in test tone so that the volume of each speaker is the
same at the listening position.
Note
• These settings cannot be calibrated in either of the following
cases:
–The “Audio TV Out” setting is set to “On” (➔ page 65).
–“HDMI Control(RIHD)” is set to “On” (➔ page 64) and
you’re listening through your TV speakers.
– The AV receiver is muted.
■ Left, Front High Left, Center
*1
, Front High Right,
Right, Surround Right, Surround Back Right,
Surround Back Left, Surround Left
` –12dB to 0dB
to +12dB in 1 dB steps.
■ Subwoofer
*1
` –15dB to 0dB to +12dB in 1 dB steps.
Note
• Speakers that you set to “No” or “None” in
“Speaker Configuration” cannot be selected (➔ page 52).
•When the “Powered Zone 2” setting is set to “Yes” and Zone 2
is turned on, the surround back and front high speakers cannot be
used.
• The test tone is output at the standard level for THX, which is
0 dB (absolute volume setting 82). If you normally listen at
volume settings below this, be careful because the test tone will
be much louder.
*1
For the center speaker and subwoofer, the level settings made
by using the Quick Setup are saved in this menu (➔ page 46).
Tip
• If you’re using a handheld sound level meter, adjust the level of
each speaker so that it reads 75 dB SPL at the listening position,
measured with C-weighting and slow reading.
Equalizer Settings
With the Equalizer settings, you can adjust the tone of
speakers individually with a 5-band equalizer. The volume
of each speaker can be set.
■ Manual Equalizer
` On:
You can adjust the equalizer for each speaker
manually. Continue with the following procedure:
` Off
:
Tone off, response flat.
Note
• When the Direct listening mode is selected, the equalizer settings
have no effect.
• If “Audyssey” is enabled, it prevails over this setting
(➔ page 57).
THX Audio Setup
■ Surr Back Speaker Spacing
` <1ft (<0.3m)
` 1ft-4ft (0.3m-1.2m)
` >4ft (>1.2m)
You can specify the distance between your surround back
speakers.
Note
• Cannot be set if:
–“Surround Back” is set to “None” (➔ page 53).
–“Surround Back Ch” is set to “1ch” (➔ page 53).
–“Powered Zone 2” is set to “Yes” (➔ page 52) and Zone 2
turned on (➔ page 69).
■ THX Ultra2/Select2 Subwoofer
` No
` Yes
If you’re using a THX-certified subwoofer, set this setting
to “Yes”.
Note
• If the “Subwoofer” setting is set to “No”, this setting cannot be
selected (➔ page 53).
■ BGC
` Off
` On
You can apply THX’s Boundary Gain Compensation
(BGC) to compensate the perceived exaggeration of low
frequencies for listeners sitting very close to a room
boundary (i.e., wall).
Note
• This setting is only available if “THX Ultra2/Select2
Subwoofer” is set to “Yes”.
• If the “Subwoofer” setting is set to “No”, this setting cannot be
selected (➔ page 53).
This setting is set automatically by Audyssey 2EQ
®
Room Correction and Speaker Setup (➔ page 32).
1
Press w to select “Channel”, and then use e/r to
select a speaker.
2
Use q/w to select a frequency, and then use the e/r
to adjust the level at that frequency.
The volume at each frequency can be adjusted from
–6dB to 0dB
to +6dB in 1 dB steps.
Tip
• You can select: “63Hz”, “250Hz”, “1000Hz”, “4000Hz”, or
“16000Hz”. And for the subwoofer, “25Hz”, “40Hz”,
“63Hz”, “100Hz”, or “160Hz”.
• Low frequencies (e.g., 63Hz) affect bass sounds; high
frequencies (e.g., 16000Hz) affect treble sounds.
3
Use q to select “Channel”, and then use e/r to
select another speaker.
Repeat steps 1 and 2 for each speaker.
You cannot select speakers that you set to “No” or
“None” in the “Speaker Configuration”
(➔ page 52).
