REF.NO. PART NO. DESCRIPTION
33 27100408 Chassis
34 27130870 Bracket, power transformer
35 27190965 Holder
36 27190693A KGLS-6RF,Holder
37 27190266 KGLS-12RF,Holder
39 830440089 4TTC+8C(BC),Self-tapping screw
40 838130088 3TTB+8B,Self-tapping screw
41 28141484 Cushion
42 27141797 Retainer, fan
43 838450108 5TTB+10B(BC),Self-tapping screw
44 27150470 Shield plate, fan
45 880016 P3035B,Plastic rivet
46 29362609 Label PT
47 27150471 Shield plate, amplifier
62 28184817 Top cover
63 29362959 Label
64 29362772 Label, cover
65 838430088 3TTB+8B(BC),Self-tapping screw
67 27175319B Leg
68 28141332 Cushion
69 831430088 3TTW+8B(BC),Self-tapping screw
86 260208 Wire tie
E821 24502310 D09T-24PG10(EX),Fan
F6901,F6902 252196 12A-UL/T-314,Fuse
T901 2301532 NPT-1420D,Power transformer
U8 1A906534-1G NAPS-7234-1G,Rectifier circuit PC board ass'y
!
65
63
65
62
64
34
45
47
4
F6901
F6902
39
T901
40
E821
42
45
37
86
37
36
35
36
69
68
67
33
41
U8
43
69
68
67
44
DTR-8.2
EXPLODED VIEW
Chassis section 1
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
