Integra Luxtec MLX 300 User Manual

9
The fuses for the light source are located in the power entry module in the rear
of the unit and may require replacement if the system does not respond to the
power switch.
To replace a fuse:
1. Remove the hospital grade power cord from the back of the light source.
2. Using a small flat screwdriver, pry open the retaining door (Figure 9) and
pry out the red plastic block from the power entry module (Figure 10).
3. Check to see if either fuse is blown; if blown, replace with a fuse of the
same rating (Integra P/N 600987).
4. Replace the red block in the housing.
5. Snap the retaining door into place.
6. Plug cord back into light source and retest the unit.
Fuse Replacement
9
10
Integra
®
Luxtec
®
MLX 300 Wa Xenon Light Source
