- 9 -
English
WARNING !
Do never try to open the cabinet of the radio. No user serviceable parts are inside the cabinet. Tampering or
modifying the circuit of the radio or its original factory adjustment may cause damage to the product, may change
the electrical specifications and will void the warranty. If service is required, please refer only to a qualified and
authorized service center.
Controls, Indicators and Operation
22. Earset-Microphone-Charge Jack
Connect an external earset-microphone to this jack. Connect the 230VAC battery travel charger (AC-520) to this jack.
WARNING !
Use only original accessories. Connecting and using accessories other than the original ones, may cause
serious damage to the radio and will void the warranty.
Always set the volume to minimum before connecting an external earset, in order to avoid damaging the earset
or the user’s ear.
23. Belt Clip
24. Battery Door
Open this cover (24) to install or remove batteries.
25. Battery Type Selector
The battery type selector (25) is located inside the battery room. Set the switch (25) to Ni if rechargeable batteries are
used. Set the switch (25) to AL if alkaline batteries are used.
