Intek M-790 plus - Rear Panel Connections

Controls and operation
- 8 -
English
Rear Panel
13. EXT (External Speaker) Jack
This jack is for connecting an external speaker (optional).
14. S-METER Jack
This jack is for connecting an external S-METER (optional).
15. ANTENNA Connector (SO-239)
Antenna connector. Refer to the section INSTALLATION OF THE ANTENNA.
16. 13.2VDC POWER CORD
13.2VDC power cord input.
ANTENNA
EXT S-METER
DC
13.2V
13 14
16
15
IMPORTANT !
Do never attempt to open the cabinet of the transceiver. No user serviceable parts inside.
Internal modifications or tampering may cause damage to the product, modify its
technical specifications and will void warranty rights. If service or repair are required,
please go to an authorised service centre or specialized technician.
