8 IB865 User’s Manual
Setting the Jumpers
Jumpers are used on IB865 to select various settings and features
according to your needs and applications. Contact your supplier if you
have doubts about the best configuration for your needs. The following
lists the connectors on IB865 and their respective functions.
Jumper Locations on IB865..........................................................9
JP1: Clear CMOS Contents........................................................10
JP2, JP3, JP4: RS232/422/485 (COM2) Selection ......................10
JP5/6/7/8/9/10/11: CRT VGA Signal Select...............................10
JP13: Primary LAN Enable/Disable...........................................11
JP14: DiskOnChip Address Select .............................................11
Jumper and Connectors on IBA120............................................12
J1: Panel Inverter Power Connector ...........................................12
JP2: Panel Voltage Setting.........................................................12
J4: TV out Connector.................................................................12
JP1: TV Type Select...................................................................13
JP2: LVDS Panel Power Select ..................................................13
J2, J3: LVDS Connectors (2nd channel, 1st channel).................13
Jumper and Connectors on IBA110............................................14
J1: TMDS Panel Connector........................................................14
J2: CRT2 / TV-Out Connector ...................................................14
J3: Panel Inverter Power Connector ...........................................15
J4: VGA Chipset Fan Power Connector .....................................15
J5, J6: LVDS Connectors (2nd channel, 1st channel).................15
JP1: LVDS Panel Power Select ..................................................15
SW1: LVDS Resolution Select...................................................16
