21
2-5-3 PCI Express Slot
The P31 Express chipset Based motherboard series offer one PCI-Express x16 graphics slot
that offers 4 Gbyte/sec data transfer rate at each relative direction which get 3.5 times of
bandwidth more than AGP8X and up to 8 Gbyte/sec concurrent bandwidth at full speed .
Fully compliant to the PCI Express Base Specification revision 1.0a, support PCI Express
VGA card, and other PCI Express device. Two PCI Express x1 I/O slots offer 512Mbyte/sec
concurrently, over 3.5 times more band width than PCI at 133Mbye/sec, tackling the most
demanding multimedia tasks nowadays. Three 32-bit PCI slots guarantee the rich connectivity
for the I/O of peripherals.
1 PCI-E x16 @16 lane Slot
2 PCI-E x1 Slots
3PCI Slots
