Intel Desktop Board DG41WV Technical Product Specification
10
Table 2 lists the components identified in Figure 1.
Table 2. Board Components Shown in Figure 1
Item/callout
from Figure 1
Descri
ption
A Conventional PCI bus add-in card connector
B Conventional PCI bus add-in card connector
C PCI Express x16 connector
D Chassis fan header
E PCI Express x1 connector
F Back panel connectors
G Keyboard power jumper block
H Processor core power connector (2 X 2)
I Piezoelectric speaker
J Intel 82G41 GMCH
K LGA775 processor socket
L Processor fan header
M DIMM 0 Channel A socket
N DIMM 0 Channel B socket
O Serial port B connector
P Floppy disk drive connector
Q Main Power connector (2 X 12)
R Battery
S Intel 82801GB I/O Controller Hub (ICH7)
T Serial ATA connectors
U Clear CMOS jumper block
V Intruder alert header
W Front panel header
X Front panel USB header
Y Front panel USB header
Z S/PDIF header
AA Front panel audio header
