Intel BLKDG41WV - Connectors and Headers Shown in Figure 2; Serial ATA Connectors

Intel Desktop Board DG41WV Technical Product Specification
14
Table 3 lists the connectors and headers identified in Figure 2.
Table 3. Connectors and Headers Shown in Figure 2
Item/callout
in Figure 2 Descri
ption
A Chassis fan header
B Processor core power connector (2 X 2)
C Processor fan header
D Serial port B connector
E Main power connector (2 X 12)
F Serial ATA connectors
G Intruder alert header
H Front panel header
I Front panel USB header
J Front panel USB header
K S/PDIF header
L Front panel audio header
Table 4 though Table 14 list the signal names for the component-side connectors and
headers.
Table 4. Serial ATA Connectors
Pin Signal Name
1 Ground
2 TXP
3 TXN
4 Ground
5 RXN
6 RXP
7 Ground
