Intel BLKDG41WV - Jumpers

Technical Reference
17
2.1.2 Jumpers
Figure 3 shows the location of the board’s jumper blocks.
Figure 3. Jumpers
Table 15 lists the jumper blocks identified in Figure 3.
Table 15. Jumpers Shown in Figure 3
Item/callout
in Figure 3 Descri
ption
A Keyboard power jumper block
B Clear CMOS jumper block
