Intel Desktop Board DG41WV Technical Product Specification
18
Table 16 and Table 17 list the settings for the jumper blocks.
Table 16. Clear CMOS Jumper Settings
Function/Mode Jumper Setting Description
Normal 1-2 The BIOS uses current configuration information and
passwords for booting.
Clear CMOS 2-3 Clears the time, date, and BIOS password.
Note: You can clear these settings by turning off the system
power and moving the jumper to pins 2 and 3. After 10
seconds, move the jumper back to pins 1 and 2 and power on
the system.
Do not leave the jumper on pins 2 and 3 while the system is
powered on or the desktop board may be damaged.
Table 17. Keyboard Power Jumper Settings
Function/Mode Jumper Setting Configuration
Disable 1-2 Disables the keyboard wake-up feature
Enable 2-3 Enables the keyboard wake-up feature (default)
