Intel Desktop Board DG41WV Technical Product Specification
16
Table 10. Front Panel Header
Pin Signal Name Pin Signal Name
1 HDLED+ 2 FP_LED+
3 HDLED- 4 FP_LED-
5 Ground 6 FP_PWRBTN#
7 FP_SYS_RST# 8 Ground
9 FPA_DET# 10 Key (no pin)
Table 11. Front Panel USB1/USB2 Header
Pin Signal Name Pin Signal Name
1 +5V_Dual 2 +5V_Dual
3 D1- 4 D2-
5 D1+ 6 D2+
7 Ground 8 Ground
9 Key (no pin) 10 No connect
Table 12. Processor Core Power Connector
Pin Signal Name Pin Signal Name
1 Ground 2 Ground
3 +12 V 4 +12 V
Table 13. Main Power Connector
Pin Signal Name Pin Signal Name
1 +3.3 V 13 +3.3 V
2 +3.3 V 14 -12 V
3 Ground 15 Ground
4 +5 V 16 PS-ON# (power supply remote on/off)
5 Ground 17 Ground
6 +5 V 18 Ground
7 Ground 19 Ground
8 PWRGD (Power Good) 20 No connect
9 +5 V (Standby) 21 +5 V
10 +12 V 22 +5 V
11 +12 V 23 +5 V
12 +3.3 V 24 Ground
Table 14. Intruder Alert Header
Pin Signal Name
1 Intruder#
2 Ground
