Intel BLKDP55WB User Manual

Intel Desktop Board DP55WB Product Guide
12
Table 2. Intel Desktop Board DP55WB Components
Label Description
A PCI bus connector
B Front panel audio header
C PCI Express 2.0 x1 connector
D PCI Express 2.0 x1 connector
E PCI Express 2.0 x16 connector
F Back panel connectors
G Rear chassis fan header
H Processor fan header
I 12 V processor core voltage connector (2 x 2 pin)
J Processor socket
K DDR3 Channel A, DIMM 0 and DIMM 1 sockets
L DDR3 Channel B, DIMM 0 and DIMM 1 sockets
M Standby power indicator LED
N Main power connector (2 x 12 pin)
O Front panel header
P Front chassis fan header
Q Battery
R Alternate front panel power LED header
S BIOS configuration jumper block
T Speaker
U Serial ATA connectors (6)
V USB 2.0 header
W USB 2.0 header with support for an Intel Z-U130 USB Solid-state Drive or
compatible device
X USB 2.0 header
Y Chassis intrusion header
Z IEEE 1394a header
AA S/PDIF header

Intel BLKDP55WB Specifications

General

Brand	Intel
Model	BLKDP55WB
Category	Motherboard
Language	English
