1 Desktop Board Features
This chapter briefly describes the features of Intel
®
Desktop Board DP55WB. Table 1
summarizes the major features of the Desktop Board.
Table 1. Feature Summary
Form Factor
MicroATX (243.84 millimeters [9.60 inches] x 243.84 millimeters
[9.60 inches])
Processor Support for an Intel
®
processor in the LGA1156 package
Main Memory
• Four 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM)
sockets arranged in two channels
• Support for DDR3 1333 MHz and DDR3 1066 MHz DIMMs
• Support for non-ECC memory
• Support for up to 16 GB of system memory
Chipset Intel
®
P55 Express Chipset consisting of the Intel
®
P55 Express
Platform Controller Hub (Intel
®
PCH)
Graphics Support for PCI Express* x16 graphics cards
Audio
• Independent multi-streaming 6-channel (5.1) audio and 2-channel
audio subsystem, featuring:
― Intel
®
High Definition (Intel
®
HD) Audio interface
― Realtek* ALC888-VC2-GR codec
• Support for Intel HD Audio and AC ’97 front panel audio
• Onboard 4-pin S/PDIF out connector
Expansion
Capabilities
• One PCI Express 2.0 x16 interface
• Two PCI Express 2.0 x1 interfaces
• One PCI* interface
Peripheral
Interfaces
• Up to 14 USB 2.0 ports:
― Eight ports routed to eight back panel USB connectors
― Six ports routed to three onboard USB headers; one header
supports an Intel
®
Z-U130 USB Solid-state Drive or compatible
device
• Up to two IEEE 1394a ports:
― One port routed to a back panel IEEE 1394a connector
― One port routed to an IEEE 1394a header
• Six Serial ATA (SATA) channels (3.0 Gb/s) via the PCH
RAID
Intel
®
Matrix Storage Technology for Serial ATA
continued
