Intel Desktop Board DQ67EP Technical Product Specification
12
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1
Descript
ion
A Back panel connectors
B Battery
C Serial port header
D 12 V internal power connector (ATX12V)
E Intel Q67 Express Chipset
F SATA connectors
G Front panel USB 2.0 header
H PCI Express Half-Mini card connector
I Main power connector (2 x 12)
J Standby power LED
K System fan header
L Front panel USB 2.0 header
M Piezoelectric Speaker
N Front panel USB 2.0 header
O Front panel header
P Alternate front panel power LED header
Q Intel Fast Call for Help (Intel FCFH) header
R Low Pin Count (LPC) Debug connector
S Chassis intrusion header
T BIOS setup configuration jumper block
U DDR3 DIMM 2 socket
V DDR3 DIMM 1 socket
W LGA1155 processor socket
X PCI Express x16 add-in card connector
Y Processor fan header
Z Intel
®
Management Engine BIOS Extension (Intel
®
MEBX) Reset header
AA S/PDIF header
BB Internal mono speaker header
CC Front panel audio header
