Intel Desktop Board DQ67EP Technical Product Specification
56
Figure 14. Intel MEBX Reset Header
Table 26. Intel MEBX Reset Header Signals
Pin Function
1 PCH.AK24 (PCH_RTCRST_PULLUP)
2 Ground
3 No connection
