Intel Desktop Board DQ67EP Technical Product Specification
14
1.2 Legacy Considerations
This board differs from other Intel Desktop Board products, with specific changes
including (but not limited to) the following:
• No floppy drive connector
• No PS/2 connector
• No Parallel ATA (PATA) IDE drive connector
1.3 Online Support
To find information about… Visit this World Wide Web site:
Intel Desktop Board DQ67EP http://www.intel.com/products/motherboard/index.htm
Desktop Board Support http://www.intel.com/p/en_US/support?iid=hdr+support
Available configurations for the Intel
Desktop Board DQ67EP
http://ark.intel.com
Supported processors http://processormatch.intel.com
Chipset information http://www.intel.com/products/desktop/chipsets/index.htm
BIOS and driver updates http://downloadcenter.intel.com
Tested memory http://www.intel.com/support/motherboards/desktop/sb/CS-
025414.htm
Integration information http://www.intel.com/support/go/buildit
1.4 Processor
The board is designed to support the Intel Core i7, Intel Core i5, Intel Core i3, and
Intel Pentium processors in an LGA1155 socket.
Other processors may be supported in the future. This board is designed to support
processors with a maximum TDP of 95 W. See the Intel web site listed below for the
most up-to-date list of supported processors.
For information about… Refer to:
Supported processors http://processormatch.intel.com
CAUTION
Use only the processors listed on the web site above. Use of unsupported processors
can damage the board, the processor, and the power supply.
NOTE
Use of a 95 W TDP processor requires a custom thermal solution. Pairing a mini-ITX
chassis and a 95 W TDP processor with the supplied standard Intel thermal solution
may not meet thermal requirements. Verify that your thermal solution and chassis
will meet the necessary thermal requirements. Failing to do so will cause the
processor to throttle, significantly decreasing system performance.
