Intel Desktop Board DQ67EP Technical Product Specification
46
Table 9. Component-side Connectors and Headers Shown in Figure 10
Item/callout
from Figure 10 Descript
ion
A Serial port header
B 12 V internal power connector (ATX12V)
C SATA connectors
D Front panel USB 2.0 header
E PCI Express Half-Mini card connector
F Main power connector (2 x 12)
G System fan header
H Front panel USB 2.0 header
I Front panel USB 2.0 header
J Front panel header
K Alternate front panel power LED header
L Intel FCFH header
M LPC Debug connector
N Chassis intrusion header
O PCI Express x16 add-in card connector
P Processor fan header
Q S/PDIF header
R Intel MEBX reset header
S Internal mono speaker header
T Front panel audio header
