Intel Braswell Series User Manual

41
USB Hardware Delays and Time-outs:
USB Transfer Time-out
Use this item to set the time-out value for control, bulk, and interrupt transfers.
The optional settings are: [1 sec]; [5 sec]; [10 sec]; [20 sec].
Device Reset Time-out
Use this item to set USB mass storage device start unit command time-out.
The optional settings are: [10 sec]; [20 sec]; [30 sec]; [40 sec].
Device Power-up Delay
Use this item to set maximum time the device will take before it properly reports
itself to the host controller.
The optional settings: [Auto]; [Manual].
‘Auto’ uses default value: for a root port it is 100 ms, for a hub port the delay is
taken from hub descriptor.
Select [Manual] you can set value for the following sub-item: ‘Device Power-up
Delay in Seconds’.
Device Power-up Delay in Seconds
The delay range is from [1] to [40] seconds, in one second increments.
 Platform Trust Technology
Press [Enter] to make settings for the following sub-item:
TPM Configuration
fTPM
The optional settings are: [Enabled]; [Disabled].
 IntelRMT Configuration
Press [Enter] to make settings for the following sub-item:
IntelRMT Configuration
Intel RMT Support
The optional settings are: [Enabled]; [Disabled].
When set as [Enabled], user can make further settings in the following item:
HW Notification
This item is for user to select hardware notification enabling status.
The optional settings are: [Disabled]; [Enabled].
