Intel
®
Core
TM
2 Duo processor with the Mobile Intel
®
945GME Express Chipset
May 2007 Manual
Order Number: 317443-001US 17
Getting Started—Intel
®
945GME Express Chipset
• Two x1 PCI Express* slots.
Note: There are actually three x1 PCI Express* slots but slot 2 was used for validation
purposes. Only slots 0 and 1 are supported.
Clocking
• CK-410M and CK-SSCD
• Battery-backed real time clock
Connector Interface Summary
• One x16 PCI Express* Video Interface, doubles as an MEC connector to provide
access to dual SDVO ports if PCI Express* is unused
•Two SATA ports
• One Ultra ATA (33/66/100) IDE connector supporting up to two IDE devices
• Eight Universal Serial Bus (USB) 2.0 ports (Five ports provided on rear-panel, three
provided via headers (J6H2, J7E2)
• Two PCI 2.3 compliant 33 MHz interface connectors
• PS/2-style keyboard and PS/2 mouse (6-pin mini-DIN) connectors
• TV Out D-connector at back panel interface
• LVDS connector on top of circuit board near GMCH (J5F1)
• One VGA connector provides access to integrated graphics
• One LAN connector providing 10/100/1000 Mbps connectivity from the Intel
82573E Gigabit Ethernet Controller
• One 9-pin serial port connector.
•One IrDA port (U4A1)
• Two PCI Express* slots (x1)
• Two SODIMM connectors on rear side of circuit board
Debug Features
• Extended Debug Port (XDP) connector
• On-board Port 80h display
Miscellaneous Features
• Configurable for ATX 1.1 Power Supply in desktop mode or AC Mobile Brick/Battery
Pack for Mobile Mode
• ATX Form Factor eight layer PCB
• AMI* system BIOS
• Two built-in fan power connectors: Chassis Fan and CPU Fan
• Power/Reset buttons
• CMOS clear jumper
• BIOS recovery jumper
• Boot Block protection jumper
• Support for Serial, IrDA, serial mouse, and keyboard
