Intel Core 2 Duo - Media Expansion Card (MEC) Slot; MEC Slot (J6 C1)

Intel
®
Core
TM
2 Duo processor with the Mobile Intel
®
945GME Express Chipset
May 2007 Manual
Order Number: 317443-001US 47
Hardware Reference—Intel
®
945GME Express Chipset
4.6.2.3 Media Expansion Card (MEC) Slot
When not being used for PCI Express*, the x16 slots can be used for Serial Digital
Video Out (SDVO). SDVO cards provide for a third party vendor secondary graphics
add-on such as a digital panel interface.
The SDVO interface will also support a Media Expansion Card (MEC), which provide TV
Capture over the PCI Express* x1 port in addition to the standard SDVO card video out
capabilities.
A70GND B70LANE 13 (T+)
A71GND B71LANE 13 (T-)
A72 LANE 13 (R+) B72 GND
A73 LANE 13 (R-) B73 GND
A74GND B74LANE 14 (T+)
A75GND B75LANE 14 (T-)
A76 LANE 14 (R+) B76 GND
A77 LANE 14 (R-) B77 GND
A78GND B78LANE 15 (T+)
A79GND B79LANE 15 (T-)
A80 LANE 15 (R+) B80 GND
A81 LANE 15 (R-) B81 PRST2#
A82 GND B82 RSVD
Table 12. PCI Express* (x16) Pinout (J6C1) (Sheet 3 of 3)
Pin Description Pin Description
Table 13. MEC Slot (J6C1) (Sheet 1 of 3)
Pin
Number
AB
1 N/C 12 V
2 12 V 12 V
3 12 V Reserved
4GND GND
5N/C N/C
6N/C N/C
7N/C GND
8 N/C 3.3 V
93.3 V N/C
10 3.3 V +3.3VA
11 RESET WAKE#
Key
12 GND Reserved
13 REFCLK+ GND
14 REFCLK- Lane 0 (T+)
15 GND Lane 0 (T-)
16 Lane 0 (R+) GND
