Intel Core 2 Duo - Supported Configuration Jumper;Switch Settings

Intel
®
945GME Express Chipset—Hardware Reference
Intel
®
Core
TM
2 Duo processor with the Mobile Intel
®
945GME Express Chipset
Manual May 2007
40 Order Number: 317443-001US
Table 8. Supported Configuration Jumper/Switch Settings (Sheet 1 of 2)
Ref Des Function Default Setting Optional Setting
J1F2
Enginnering Validation
(EV) Support
Out - Normal Operation Not supported
J1F4 BSEL2 1-2 CPU Driven FSB Frequency
2-3 Force FSB Frequency - See schematic for valid
combinations
J1G1 BSEL1 1-2 CPU Driven FSB Frequency
2-3 Force FSB Frequency - See schematic for valid
combinations
J1G2 BSEL0 1-2 CPU Driven FSB Frequency
2-3 Force FSB Frequency - See schematic for valid
combinations
J2B2 IMVP-6 Test Out - Normal Operation Not supported
J2G1 CPU Clock Test Out - Normal Operation Not supported
J2J1 EV Support Out - Normal Operation Not supported
J2J10
CRB/System Validation
(SV) Detect
2-3 - Normal Operation Not supported
J2J11 EV Support Out - Normal Operation Not supported
J2J12 EV Support Out - Normal Operation Not supported
J2J2 EV Support Out - Normal Operation Not supported
J2J3 EV Support Out - Normal Operation Not supported
J2J4 EV Support Out - Normal Operation Not supported
J2J5 EV Support Out - Normal Operation Not supported
J2J6 EV Support Out - Normal Operation Not supported
J2J7 EV Support Out - Normal Operation Not supported
J2J8 EV Support Out - Normal Operation Not supported
J2J9 EV Support Out - Normal Operation Not supported
J3B1
Thermal Diode
Connection
1-2 Connect CPU THERMDA to
Sensor
3-4 Connect CPU THERMDC to
Sensor
Out - Disconnect CPU from Thermal Sensor
Out - Disconnect CPU from Thermal Sensor
J3H1 Shutdown Out - Normal Operation In - Force the board to shut down
J3J1 EV Support Out - Normal Operation Not supported
J3J2 EV Support Out - Normal Operation Not supported
J5H2 SATA HotSwap In - Normal Operation Out - Disable SATA Hotswap
J6C2 EVMC Schmoo Header Out - Normal Operation Not supported
J6D1 EVMC Schmoo Header Out - Normal Operation Not supported
J6E1 LVDS Panel Power Jumper 2-3 and 5-6 - Normal Operation Not supported
J6G1 EVMC Schmoo Header Out - Normal Operation Not supported
J6H1 CMOS Clear Out - Normal Operation In - Clear the CMOS
J7A2 82573E PHY Test Out - Normal Operation Not supported
J7A3 KBC Program 1-2 Normal Operation 2-3 Connect RxD to KBC for programming
J7A4 KBC Program 1-2 Normal Operation 2-3 Connect TxD to KBC for programming
J7B1 82573E Clock View Out - Normal Operation Not supported
J7E1 Port80 Select Out - Normal Operation Not supported
J7E2 Enable SPI Boot BIOS Out - Normal Operation Not supported
J7E3 SuperIO Reset 1-2 Normal Operation 2-3 to hold the SIO in reset
