Intel Core 2 Duo - Page 41

Intel
®
Core
TM
2 Duo processor with the Mobile Intel
®
945GME Express Chipset
May 2007 Manual
Order Number: 317443-001US 41
Hardware Reference—Intel
®
945GME Express Chipset
J7J3 PATA Hotswap In - Normal Operation Out - Disable PATA Hotswap
J8A1
LAN Non-volatile
Memory Protect
Out - Normal Operation Not supported
J8G1 KBC Reset 1-2 Normal Operation 2-3 to hold the KBC in reset
J8G2 SV Set Up Out - Normal Operation Not supported
J8H1 BIOS Recovery Out - Normal Operation In - Recover the BIOS
J9G3 Boot Block Program In - Normal Operation Not supported
J9H1
Non-Maskable Interrupt
Jumper (1 Hz Clock)
Out - Normal Operation In - Enable KBC programming
J9J1 KBC Disable Out - Normal Operation In - KBC Disabled
J9J2 Mode Type (MD) 0 In - Normal Operation Not supported
J9J3 SATA Device Status In - Normal Operation Not supported
J9J4 MD2 Out - Normal Operation Not supported
J9J5 LID Jumper Out - Normal Operation In - LID Jumper closed
J9J6 MD1 In - Normal Operation Not supported
J9J7 Virtual Battery Jumper Out - Normal Operation Not supported
SW9J1 Virtual Battery Switch 1-2 Normal Operation Not supported
SW9J2 Lid Switch 1-2 Normal Operation 2-3 LID Switch closed
Table 8. Supported Configuration Jumper/Switch Settings (Sheet 2 of 2)
Ref Des Function Default Setting Optional Setting
