945GME Express Chipset—Hardware Reference
Intel
®
Core
TM
2 Duo processor with the Mobile Intel
®
945GME Express Chipset
Manual May 2007
50 Order Number: 317443-001US
A5 (JTAG) TCK B5 SMCLK
A6 (JTAG) TDI B6 SMDAT
A7 (JTAG) TDO B7 GND
A8 (JTAG) TMS B8 +3.3 V
A9 +3.3 V B9 (JTAG) TRST#
A10 +3.3 V B10 +3.3 VAUX
A11 PERST# B11 WAKE#
A12GND B12RSVD
A13REFCLK+ B13GND
A14REFCLK- B14LANE 0 (T+)
A15GND B15LANE 0 (T-)
A16LANE 0 (R+)B16GND
A17 LANE 0 (R-) B17 PRSNT2*
A18GND B18GND
Table 14. PCI Express* (x1) Pinout (J7C1, J8C1) (Sheet 2 of 2)
