Intel Desktop Board D2550MUD2 Technical Product Specification
14
Table 2. Board Components Shown in Figure 1
Item/callout
from Figure 1 Description
A
LVDS inverter panel voltage selection jumper
B
Back panel connectors
C
S/PDIF header
D
Standby power LED
E
Processor core power connector (2 x 12)
F
LVDS panel connector
G
Intel Atom processor
H
Trusted Platform Module (TPM) header
I
SO-DIMM channel A socket, DIMM 1
J
SO-DIMM channel A socket, DIMM 0
K
Intel NM10 Express Chipset
L
SATA connectors
M
System fan header
N
Front panel header
O
BIOS setup configuration jumper block
P
Battery
Q
Front panel USB 2.0 header
R Front Panel Wireless Activity LED header
S
Piezo/monotonic speaker header
T
Conventional PCI bus add-in card connector
U
PCI Express Full-/Half-Mini Card slot
V Serial port header, COMM 2
W
FPD brightness connector
X
LVDS inverter power voltage selection jumper
Y
Front panel audio header
Z
Front panel USB header that supports an Intel Z-U130 USB
Solid-State Drive or compatible device (brown-colored))
AA
Serial port header, COMM 1
