Intel Desktop Board D2550MUD2 Technical Product Specification
44
Table 10 lists the component-side connectors and headers identified in Figure 11.
Table 10. Component-side Connectors and Headers Shown in Figure 11
Item/callout
from Figure 11 Description
A
LVDS inverter panel voltage selection jumper
B
S/PDIF header
C
Processor core power connector (2 x 12)
D
LVDS panel connector
E
TPM header
F
SATA connector
G
SATA connector
H
System fan header
I
Front panel header
J
Front panel USB 2.0 header
K
Front panel wireless activity LED header
L
Piezo/monotonic speaker header
M
PCI Express Full-/Half-Mini Card slot
N Conventional PCI bus add-in card connector
O Serial port header, COMM 2
P
FPD brightness connector
Q
LVDS inverter power voltage selection jumper
R
Front panel audio header
S
Front panel USB header that supports an Intel Z-U130 USB Solid-State Drive or
compatible device (brown-colored)
T
Serial port header, COMM 1
