Intel D2550MUD2 User Manual

Intel Desktop Board D2550MUD2 Technical Product Specification
24
1.8 LAN Subsystem
The LAN subsystem consists of the following:
• Intel NM10 Express Chipset
• Intel 82574L Gigabit Ethernet Controller for 10/100/1000 Mb/s Ethernet LAN
connectivity
• RJ-45 LAN connector with integrated status LEDs
Additional features of the LAN subsystem include:
• CSMA/CD protocol engine
• LAN connect interface that supports the Ethernet controller
• Conventional PCI bus power management
 Supports ACPI technology
 Supports LAN wake capabilities
1.8.1 LAN Subsystem Drivers
LAN drivers are available from Intel’s World Wide Web site.
For information about Refer to
Obtaining LAN drivers Section 1.2, page 16

Intel D2550MUD2 Specifications

General

Brand	Intel
Model	D2550MUD2
Category	Motherboard
Language	English
