Intel D945GCL User Manual

Intel Desktop Board D945GCL Product Guide
12
Table 2. Desktop Board D945GCL Components
Label Description
A PCI Express x1 connector
B Front panel audio header
C PCI bus connector 2
D PCI bus connector 1
E PCI Express x16 connector
F Back panel connectors
G 12 V processor core voltage connector (2 x 2 pin )
H Rear chassis fan header (3-pin)
I Processor socket
J Processor fan header (4-pin)
K DIMM 0, Channel A socket
L DIMM 0, Channel B socket
M Main power connector (2 x 12 pin)
N Diskette drive connector
O IDE connector
P Battery
Q Front chassis fan header (3-pin)
R BIOS configuration jumper block
S Chassis intrusion header
T Serial ATA connectors
U Alternate front panel power LED header
V Front panel header
W Hi-speed USB 2.0 headers
X Speaker
Related Links:
Go to the following links for more information about:
• Desktop Board D945GCL
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
• Supported processors
http://support.intel.com/support/motherboards/desktop
• Audio software and utilities
http://www.intel.com/design/motherbd
• LAN software and drivers
http://www.intel.com/design/motherbd
