Intel Desktop Board D945GCL Product Guide
30
Installing and Removing a Processor
Instructions on how to install the processor on the desktop board are given below.
Installing a Processor
CAUTION
Before installing or removing the processor, make sure the AC power has been
removed by unplugging the power cord from the computer; the standby power LED
should not be lit (see
Figure 3 on page 22). Failure to do so could damage the
processor and the board.
To install a processor, follow these instructions:
1. Observe the precautions in "
Before You Begin" on page 25.
2. Open the socket lever by pushing the lever down and away from the socket
(
Figure 6, A and B).
Figure 6. Lift Socket Lever
