Intel Desktop Board D945GCL Product Guide
46
Connecting to the Alternate Front Panel Power LED
Header
Figure 20, D on page 43 shows the location of the alternate front panel power LED
header. Pins 1 and 3 of this header duplicate the signals on pins 2 and 4 of the front
panel header. If your chassis has a three-pin power LED cable, connect it to this
header.
Table 9 shows the pin assignments for the front panel header.
Table 9. Alternate Front Panel Power LED Header
Pin Description In/Out
1 Front panel green LED Out
2 No pin
3 Front panel yellow LED Out
