Intel Desktop Board D945GCL Product Guide
14
NOTE
Regardless of the DIMM type used, the memory frequency will either be equal to or
less than the processor system bus frequency. For example, if DDR2 667 memory is
used with a 533 MHz system bus frequency processor, the memory will operate
at 533 MHz.
Table 3 lists the resulting operating memory frequencies based on the
combination of DIMMs and processors.
Table 3. Memory Operating Frequencies
DIMM Type
Processor System Bus
Frequency
Resulting Memory
Frequency
DDR2 400 533 400
DDR2 400 800 400
DDR2 400 1066 400
DDR2 533 533 533
DDR2 533 800 533
DDR2 533 1066 533
DDR2 667 533 533
DDR2 667 800 667
DDR2 667 1066 667
Related Links:
Go to the following links or pages for more information about:
• SDRAM specifications,
http://www.intel.com/technology/memory/
• Installing memory, page
35 in Chapter 2
