Intel D945GCPE - Desktop Board Motherboard User Manual

Intel Desktop Board D945GCPE Product Guide
12
Table 2. Desktop Board D945GCPE Components
Label Description
A Front panel audio header
B PCI bus connector 2
C PCI bus connector 1
D Rear chassis fan header (3-pin)
E Back panel connectors
F 12 V processor core voltage connector (2 x 2 pin)
G Processor socket
H Processor fan header (4-pin)
I DIMM 0, Channel A socket
J DIMM 0, Channel B socket
K Main power connector (2 x 12 pin)
L Diskette drive connector
M IDE connector
N Battery
O Serial ATA connectors
P Alternate front panel power LED header
Q Front panel header
R BIOS configuration jumper block
S Chassis intrusion header
T Hi-speed USB 2.0 headers
U Serial port header
Related Links:
Go to the following links for more information about:
• Desktop Board D945GCPE
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
• Supported processors
http://www.intel.com/go/FindCPU
• Audio software and utilities
http://www.intel.com/design/motherbd
• LAN software and drivers
http://www.intel.com/design/motherbd

Intel D945GCPE - Desktop Board Motherboard Specifications

General

Form Factor	Micro ATX
Socket	LGA 775
Memory Type	DDR2
Memory Slots	2 x DIMM
Maximum Memory	2 GB
Graphics	Intel Graphics Media Accelerator 950
Expansion Slots	1 x PCIe x16, 2 x PCI
USB Ports	8 x USB 2.0
Chipset	Intel 945GC Express
Processor Support	Intel Pentium 4, Intel Pentium D, Intel Celeron D
Storage Interface	4 x SATA, 1 x PATA
