Intel Desktop Board D945GCPE Product Guide
46
Setting the BIOS Configuration Jumper
NOTE
Always turn off the power and unplug the power cord from the computer before
moving the jumper. Moving the jumper with the power on may result in unreliable
computer operation.
Figure 23 shows the location of the desktop board’s BIOS configuration jumper block.
Figure 23. Location of the BIOS Configuration Jumper Block

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intel D945GCPE - Desktop Board Motherboard and is the answer not in the manual?

Intel D945GCPE - Desktop Board Motherboard Specifications

General IconGeneral
Form FactorMicro ATX
SocketLGA 775
Memory TypeDDR2
Memory Slots2 x DIMM
Maximum Memory2 GB
GraphicsIntel Graphics Media Accelerator 950
Expansion Slots1 x PCIe x16, 2 x PCI
USB Ports8 x USB 2.0
ChipsetIntel 945GC Express
Processor SupportIntel Pentium 4, Intel Pentium D, Intel Celeron D
Storage Interface4 x SATA, 1 x PATA
