Intel Desktop Board D945GCPE Product Guide
26
Installing and Removing the Desktop Board
CAUTION
Only qualified technical personnel should do this procedure. Disconnect the computer
from its power source before performing the procedures described here. Failure to
disconnect the power before you open the computer can result in personal injury or
equipment damage.
Do not lift or handle the desktop board by the chipset heat sink. Handling may damage
the thermal interface material that resides between the heat sink and the chipset
silicon.
Refer to your chassis manual for instructions on installing and removing the desktop
board.
Figure 5 shows the location of t
h
e mounting screw holes for Desktop Board D945GCPE.
Figure 5. Desktop Board D945GCPE Mounting Screw Hole Locations

Intel D945GCPE - Desktop Board Motherboard Specifications

General

Form Factor	Micro ATX
Socket	LGA 775
Memory Type	DDR2
Memory Slots	2 x DIMM
Maximum Memory	2 GB
Graphics	Intel Graphics Media Accelerator 950
Expansion Slots	1 x PCIe x16, 2 x PCI
USB Ports	8 x USB 2.0
Chipset	Intel 945GC Express
Processor Support	Intel Pentium 4, Intel Pentium D, Intel Celeron D
Storage Interface	4 x SATA, 1 x PATA
