Intel Desktop Board D945GCPE Product Guide
44
Connecting Chassis Fan and Power Cables
Connecting a Chassis Fan Cable
Connect the chassis fan cable to the chassis fan header on the desktop board.
Figure 21 shows the location of the chassis fan header.
Figure 21. Location of Chassis Fan Header

Intel D945GCPE - Desktop Board Motherboard Specifications

General

Form Factor	Micro ATX
Socket	LGA 775
Memory Type	DDR2
Memory Slots	2 x DIMM
Maximum Memory	2 GB
Graphics	Intel Graphics Media Accelerator 950
Expansion Slots	1 x PCIe x16, 2 x PCI
USB Ports	8 x USB 2.0
Chipset	Intel 945GC Express
Processor Support	Intel Pentium 4, Intel Pentium D, Intel Celeron D
Storage Interface	4 x SATA, 1 x PATA
