Intel Desktop Board DB85FL Technical Product Specification
14
Table 2 lists the components identified in Figure 1.
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1 Description
A PCI Express x1 add-in card connector
B PCI Express x16 add-in card connector
C Battery
D PCI Express x1 add-in card connector
E Back panel connectors
F Processor core power connector (2 x 2)
G LGA1150 processor socket
H Processor fan header
I DIMM 3 (Channel A DIMM 0)
J DIMM 1 (Channel A DIMM 1)
K DIMM 4 (Channel B DIMM 0)
L DIMM 2 (Channel B DIMM 1)
M Front fan header
N Trusted Platform Module header
O Power supervisor LED
P Enhanced standby power LED
Q Main power connector (2 x 12)
R BIOS security jumper
S Piezoelectric speaker
T Front panel USB 3.0 connector
U Intel B85 Express Chipset
V Chassis intrusion header
W Front panel header
X Alternate front panel power/sleep LED header
Y SATA 3.0 Gb/s connectors
Z SATA 6.0 Gb/s connectors
AA Front panel dual-port USB 2.0 connectors
BB Rear chassis fan header
CC S/PDIF out header
DD Front panel audio connector
