Technical Reference
43
Table 11 lists the component-side connectors and headers identified in Figure 9.
Table 11. Component-side Connectors and Headers Shown in Figure 9
Item/callout
from Figure 9
Description
A PCI Express x1 add-in card connector
B PCI Express x16 add-in card connector
C PCI Express x1 add-in card connector
D Processor core power connector (2 x 2)
E Processor fan header
F Front fan header
G TPM header
H Main power connector (2 x 12)
I Front panel USB 3.0 connector
J Chassis intrusion header
K Front panel header
L Alternate front panel power/sleep LED header
M SATA 3.0 Gb/s connectors
N SATA 6.0 Gb/s connectors
O Front panel dual-port USB 2.0 connector
P Front panel dual-port USB 2.0 connector
Q Rear chassis fan header
R S/PDIF out header
S Front panel audio connector
