1.3.1.3 High Definition Multimedia Interface* (HDMI*)
The High-Definition Multimedia Interface (HDMI) is provided for transmitting
uncompressed digital audio and video signals to television sets, projectors and other
video displays. It can carry high quality multi-channel audio data and all standard and
high-definition consumer electronics video formats. The HDMI display interface
connecting the processor and display devices utilizes transition minimized differential
signaling (TMDS) to carry audiovisual information through the same HDMI cable. The
processor HDMI interface is designed according to the High-Definition Multimedia
Interface Specification with 3D, 4K, Deep Color, and x.v.Color.
The maximum supported resolution is 4096 x 2304 @ 24Hz or 2560 x 1600 @ 60Hz.
The HDMI interface supports the HDMI 1.4a specification.
Depending on the type of add-in card installed in the PCI Express x16 connector, the
HDMI port will behave as described in Table 4.
Table 4. HDMI Port Status Conditions
PCI Express x16 Connector Status HDMI Port Status
PCI Express x16 add-in card installed
Note: May require BIOS setup menu changes.
1.3.1.4 High-bandwidth Digital Content Protection (HDCP)
HDCP is the technology for protecting high definition content against unauthorized
copy or interception between a source (computer, digital set top boxes, etc.) and the
sink (panels, monitor, and TVs). The PCH supports HDCP 1.4 for content protection
over wired displays (HDMI and DVI).
