Intel Desktop Board DB85FL Technical Product Specification

Table 19. Processor, Front, and Rear Chassis

(4-Pin) Fan Headers

Pin Signal Name

1 Ground

(Note)

2 +12 V

3 FAN_TACH

4 FAN_CONTROL

Note: These fan headers use Pulse Width Modulation control for fan speed.

Table 20. Chassis Intrusion Header

Pin Signal Name

1 Intruder#

2 Ground

Table 21. TPM Header

Pin Signal Name Pin Signal Name

1 PCICLK 2 GND

3 FRAME 4 Key (no pin)

5 PCIRST 6 N/C

7 LAD3 8 LAD2

9 VCC3 10 LAD1

11 LAD0 12 GND

13 N/C 14 N/C

15 3VSB 16 SERIRQ

17 GND 18 CLKRUN

19 PWRDWN 20 N/C

2.2.2.2 Add-in Card Connectors

The board has the following add-in card connectors:

• One PCI Express x16 (3.0/2.x/1.x)

• Two PCI Express x1 (2.x/1.x)
